Product Description

Challenger Lifts E15 15,000lb. Heavy Duty 2-Post Lift

Challenger Lifts designed their new E15 2-post lift to be an economic option for servicing vehicles up to 15,000 lbs. Heavy-duty 2-stage front and 2-stage rear arms offer symmetric lifting capability. Includes a built-in 2 foot column height extension to accommodate higher profile vehicles. The E15 also comes standard with stack adapters.

This lower cost option doesn’t sacrifice the features you’ve come to expect. The jacketed single-point mechanical lock release system was once exclusive to the domestically made CL Series lift models.

**Free shipping to Continental United States.** Delivery will be made by motor freight. Customer is responsible for unloading the lift from delivery truck. Does not include installation, though installation is available locally.

Free shipping if drop shipped from the factory (subject to factory lead time). In-stock lifts at Melrose may be picked up at our warehouse, with local installation/delivery available.

Manufacturer's warranty, 1 year labor, 1 year functional parts, and 5 year structural parts.

Features

15,000 lb. lift capacity
Heavy-duty 2-stage arms enable heavy-duty symmetric lifting
Adjustable column height accommodates higher profile vehicles and provides maximum headroom to work underneath vehicles
Jacketed pulley-less single-point mechanical lock release system that was once exclusive to CL Series models
Padded overhead shut off system prevents vehicle damage
Powder coat finish provides long-lasting durability
Plated arm restraints and arm pins inhibit rust and provide long-lasting durability
Heavy-duty polyurethane screw pads accommodate a wide range of recommended lifting points
Standard dual integrated rubber door guards help protect vehicle panels from inadvertent damage
ALI Certified

Specifications

Model Number	E15
Lifting Capacity	15,000 lbs.
Lift Configuration	Symmetric
Rise Height	6' 5-3/4"
Overall Height	14' 6" / 16' 6"
Overall Width	12' 3-1/16"
Drive Thru Clearance	9' 1-3/8"
Floor to Overhead Switch	13' 10" / 15' 10"
Front Arm Reach	Min: 36-1/2" Max: 55"
Rear Arm Reach	Min: 36-1/2" Max: 55"
Screw Pad Height	Min: 5-1/4" Max: 6-3/4"
Rise Time	Min. 5” Max. 6.5”
Required Ceiling Height	14' 7" / 16' 7"
ALI Certified	Yes
Available Colors	Textured Red, Textured Blue
